MODEL
NO. |
MTV-63V3H |
|||
|
TV
SYSTEM |
NTSC |
PAL |
||
|
SENSOR |
1/3-inch
CCD Image Sensor |
|||
|
CCD
TOTAL PIXELS |
811(H) X 508(V) |
795(H) X 596(V) |
||
|
SCANNING
SYSTEM |
525
lines, 60 fields/sec |
625
lines, 50 fields/sec |
||
|
SYNC
SYSTEM |
Internal / VD-Lock / Ext-VBS (Select by OSD) |
|||
|
MINIMUM ILLUMINATION |
Legacy
mode |
0.8 Lux ( F1.2, 5600ºK) |
||
|
Start
light Mode |
0.008 Lux ( F1.2, 5600ºK) |
|||
|
RESOLUTION |
520 TVL |
|||
|
WHITE
BALANCE |
Mode |
ATW
/ AWC / FIX ( Zero
color rolling) |
||
|
Range |
3200
~ 10000 ºK (
2200 ~ 15000 ºK with S Filter) |
|||
|
GAIN
CONTROL |
Mode |
AGC
(ON / OFF) |
||
|
Range |
0
~ 18dB |
|||
|
S
/ N RATIO
|
52dB
( MIN) / 60dB ( TYP ) (AGC
OFF) |
|||
|
ELECTRONIC
SHUTTER |
1/60~1/120,000
sec. |
1/50~1/120,000
sec. |
||
|
AUTO
IRIS |
A.E.S. / DC / Video |
|||
|
OSD
DISPLAY |
ON
SCREEN DISPLAY FOR ALL CONTROL |
|||
|
5
PUSH SW |
FOR
OSD CONTROL PANEL |
|||
|
PICTURE EHANCE |
SELECTABLE BY OSD MANUAL |
|||
|
FLICKERLESS |
SELECTABLE
BY OSD MANUAL |
|||
|
MIRROR
FUNCTION |
SELECTABLE BY OSD MANUAL |
|||
|
B.L.C.
FUNCTION |
SELECTABLE BY OSD MANUAL |
|||
|
ENHANCE |
SELECTABLE BY OSD MANUAL |
|||
|
DIGITAL
ZOOM (2X) |
SELECTABLE BY OSD MANUAL |
|||
|
NEGATIVE
IMAGE |
SELECTABLE BY OSD MANUAL |
|||
|
MASKING
AREA |
SELECTABLE BY OSD MANUAL |
|||
|
AGC
GAIN ADJUSTMENT |
SELECTABLE
BY OSD MANUAL |
|||
| PICTURE FREEZE | ON/OFF & Ext.-Trigger & Alarm In | |||
| ALARM OUT | Motion Det. | |||
| RS-232C I/F | DIM connector | |||
|
VIDEO
OUTPUT |
1.0V p-p at 75 ohm |
|||
|
GAMMA
CORRECTION |
1 / 0.45 |
|||
|
OPERATION
TEMPERATURE |
-20℃ TO 50℃ |
|||
|
OPERATIONAL
HUMIDITY |
within
85％ RH |
|||
|
POWER
SUPPLY |
DC12V & AC24V / 3W |
|||
＊The
specifications and appearance of the product may changed without notice.
＊ATW: Auto tracking white balance.
＊AWC: One push lock white balance.
Dimension (Unit : mm)
