FiberLink Receving Converter Box

Convert FiberLink signal to HD-SDI or HDMI
Support RS-232C serial communication.
HD-video format :720p@25/30/50/60,1080p@25/30,1080i@50/60
Real-time status LED indicators for troubleshooting and monitoring

Model:61F2S-D Rx Converter(FiberLink to HD-SDI)
Model:61F2H-D Rx Converter(FiberLink to HD-HDMI)

I/O	Description	61F2S-D	61F2H-D
Fiber-Inputs	Fiber‐Optical SC type Single mode X1 ch Wavelength:1310/1550nm                                               Bandwidth:2.5G(Down-streaming )/ 6M(Up-streaming) Audio format-in : 2ch(Optinal function) AUX linking: Ctrl bi-directional.	Y	Y
BNC-Outputs	Format: HD-SDI (SMPTE 292M) Supported Video-out 720p 50/60, 1080i 50/60,1080p25/30 Without Audio	Y	N
HDMI –Outputs	Supported Video-out 720p 50/60, 1080i 50/60,1080p25/30 Without Audio	N	Y
Power supply-in	DC 12V Regulated/ 500mA	Y	Y
AUX-port:	RS-232/ RS-485 (Optional), GPIO(Optional),	Y	Y

Order info.
Model:61F2S-FD Rx Converter(FiberLink to HD-SDI)<br>
Model:61F2H-FD Rx Converter(FiberLink to HD-HDMI)<br>

Application Guide:
