FiberLink Transceiver Converter Box

Convert Hd-SDI signal to FiberLink
Support RS-232C serial communication.
HD-video format :720p@25/30/50/60,1080p@25/30,1080i@50/60
Real-time status LED indicators for troubleshooting and monitoring
Model:61S2FS-D Tx Converter(FiberLink to HD-SDI)
I/O Description
Fiber-Output Fiber‐Optical SC type Single mode X1 ch
Wavelength:1310/1550nm
Bandwidth:2.5G(Down-streaming )/ 6M(Up-streaming)
Audio format-in : 2ch(Optinal function)
AUX linking: Ctrl bi-directional.

BNC-Outputs HD-SDI Loop Out(SMPTE 292M)
Supported Video-out
720p 50/60, 1080i 50/60,1080p25/30
Without Audio

BNC–Inputs Supported HD-SDI -in
720p 50/60, 1080i 50/60,1080p25/30
Without Audio

Power supply-in DC 12V Regulated/ 500mA
AUX-port: RS-232/ RS-485 (Optional), GPIO(Optional),



Order info.
Model:61S2FS-D Tx Converter(FiberLink to HD-SDI)

Application Guide:
